Gigabyte GB-BACE-3160
143.67 EUR
Tiny 0.69‑L barebone PC powered by Intel Celeron J3160 up to 2.24 GHz, HD 400 graphics, Wi‑Fi 802.11ac and Bluetooth 4.0. Includes HDMI, VGA, two USB 3.0 ports, Gigabit LAN, M.2/SATA slot, single DDR3L SO‑DIMM, Kensington lock.
Share: ![]()
![]()
![]()
![]()
![]()
![]()
REICHELT IE | Brand | Gigabyte |
| EAN | 4719331216719 |
| ASIN | B01M18SF5A |
| Model | GB-BACE-3160 |
| MPN | GB-BACE-3160-BWUP |
| SKU | GB-BACE-3160-BWUP |
| AC adapter output current | 2.1 A |
| AC adapter output voltage | 19 |
| AC input voltage | 100 - 240 V |
| Bluetooth | Yes |
| Bluetooth version | 4 |
| Built-in processor | Yes |
| Cable Lock Slot | Yes |
| Cable lock slot type | Kensington |
| Card reader integrated | Yes |
| Case colour | Black |
| Case type | Mini PC |
| Chassis type | 0.69L Sized PC |
| Compatible memory cards | MicroSD (TransFlash) |
| CPU Family | Intel Celeron |
| CPU Speed | 2.2 GHz |
| DC-in jack | Yes |
| Depth | 114.4 mm |
| Embedded options available | No |
| Ethernet LAN | Yes |
| Ethernet lan connection | Y |
| Ethernet LAN ports | 1 |
| Execute disable bit | Yes |
| Form factor | Portable |
| Graphics adapter | HD Graphics 400 |
| Graphics adapter family | Intel |
| Harmonized System HS code | 84713000 |
| Height | 56.1 mm |
| Integrated Graphics | Yes |
| Integrated Network | Yes |
| Integrated Sound | Yes |
| Intel 64 | Yes |
| Intel clear video technology | Yes |
| Intel intru 3d technology | N |
| Intel rapid storage technology | No |
| Intel smart connect technology | No |
| Intel Stable Image Platform Program | No |
| Intel trusted execution technology | No |
| Intel Virtualization Technology for Directed I/O | No |
| Intel VT-x with Extended Page Tables | Yes |
| Internal expansion bays | 1 x 2.5 inch |
| LAN controller | Realtek RTL8111H |
| Maximum internal memory | 8192 MB |
| Maximum resolution | 3840 x 2160 pixels |
| Memory Bus Speed | 1600 MHz |
| Memory slots type | SO-DIMM |
| Memory voltage | 1.35 V |
| Microphone in | Yes |
| Network card data link protocol | Gigabit Ethernet |
| Network Card Speeds | 10/100/1000 Mbps |
| On-board graphics adapter | Yes |
| On/off switch | Yes |
| Operating system | Not Included |
| Operating temperature | 0 - 35 °C |
| Panel mounting interface | 75 x 75 mm |
| PCI Express configurations | 2 x 1,1 x |
| PCI Express slots version | 2 |
| Power Supply Type | External AC adapter |
| Processor ARK ID | 91533 |
| Processor boost frequency | 2.24 GHz |
| Processor codename | Braswell |
| Processor frequency | 1.6 GHz |
| Processor lithography | 14 nm |
| Processor model | J3160 |
| RJ-45 ports | 1 x RJ-45 |
| Secure digital | Supported: microSD |
| Skip audio test | Yes |
| Sound card | Realtek ALC255 |
| Storage drive sizes supported | 2.5" |
| Storage temperature | -20 - 60 °C |
| Supported memory types | DDR3L-SDRAM |
| Supported storage drive types | HDD,SSD |
| Thermal design power | 6 W |
| Thermal monitoring technologies | Yes |
| VESA Mounting | Yes |
| Wi-Fi | Yes |
| Width | 107.6 mm |
| Wired network | Yes |
| Wireless LAN | 802.11ac |
| Wireless Network | Yes |
