A68HM‑Plus ASUS Micro ATX AM2+ DDR3 PCB
Share: ![]()
![]()
![]()
![]()
![]()
![]()
eBay
| Brand | ASUS |
| MPN | 90MB0L40-M0EAY0 |
| EAN | 5054629705711 |
| Model | B99R132 |
| ASIN | B00QH59C60 |
| ACPI version | 4.0a |
| Audio output channels | 7.1 channels |
| BIOS memory size | 64 Mbit |
| BIOS type | UEFI AMI |
| Cables included | SATA |
| Chassis intrusion connector | Yes |
| Compatible processor series | AMD A |
| Component for | PC |
| Cooling type | Passive |
| CPU fan connector | Yes |
| Depth | 183 mm |
| Drivers included | Yes |
| DVI-D ports quantity | 1 |
| Energy Star certified | No |
| Ethernet interface type | Fast Ethernet,Gigabit Ethernet |
| Ethernet LAN | Yes |
| Front panel audio connector | Yes |
| LAN controller | Realtek RTL8111GR |
| Maximum internal memory | 32 GB |
| Memory channels | Dual-channel |
| Memory slots type | DIMM |
| Microphone in | Yes |
| Motherboard chipset | AMD A68H |
| Motherboard chipset family | AMD |
| Motherboard form factor | Micro ATX |
| Non-ECC | Yes |
| Number of memory slots | 2 |
| Number of SATA III connectors | 4 |
| Parallel processing technology support | Not supported |
| Power source type | ATX |
| RAID levels | 0,1,5,10,JBOD |
| S/PDIF out connector | Yes |
| Supported memory clock speeds | 1333,1600,1866,2133,2400 MHz |
| Supported memory types | DDR3-SDRAM |
| Supported storage drive interfaces | Serial ATA III |
| TPM connector | Yes |
| Unbuffered memory | Yes |
| Width | 226 mm |
