Asrock B450 Gaming-ITX/AC
115.66 GBP
Mini‑ITX motherboard powered by AMD B450, supporting Ryzen CPUs with integrated Vega graphics, dual DDR4 slots up to 32 GB, one M.2 NVMe slot, PCIe x16 for a single GPU, HDMI and DisplayPort 1.2 outputs, Gigabit LAN, Wi‑Fi/BT 4.2, USB 3.1 Gen 2 Type‑C, Realtek ALC1220 7.1‑channel audio, RGB LED header and robust power delivery.
Share: ![]()
![]()
![]()
![]()
![]()
![]()
Quzo | Brand | ASRock |
| EAN | 4717677336238 |
| ASIN | B07FVVNDFX |
| Model | B450 GAMING-ITX/AC |
| MPN | B450 GAMING-ITX/AC |
| SKU | B450 GAMING-ITX/AC |
| 64-bit Support | Yes |
| Addressable RGB | Yes |
| AMD CrossFire Support | Not Supported |
| Audio | Realtek ALC1220 7.1 HD Audio |
| Audio line in ports | 1 x 3.5mm Jack |
| Audio Line Out Ports | 4 x 3.5mm Jacks |
| Bluetooth | Yes |
| Bluetooth version | b4.2 |
| Board dimensions | 170 x 170 mm |
| Chipset | AMD B450 |
| Chipset manufacturer | AMD |
| Cooling fan support | 1 x CPU fan2 x Chassis/Water Pump fan |
| CPU Socket | Socket AM4 |
| Dimensions | 23 x 39 x 40cm (W x H x D) |
| Displayport connection | Yes |
| DisplayPorts | 1 x DisplayPort 1.2 |
| Drivers | Included |
| DVI connection | No |
| Edition | Fatal1ty B450 Gaming ITX/ac |
| Expansion slots | 1 x M.2, 22-80, PCIe Gen3 1 x M.2, Pre-installed with Wi-Fi/Bluetooth module 1 x PCIe 3.0 x16 |
| Firewire | No |
| Form factor | Mini-ITX Motherboard |
| Front panel connectors | 1 x Front Panel1 x Front Audio |
| HDMI connection | Yes |
| HDMI Port | 1 x HDMI |
| Integrated Graphics Supported | Yes |
| Integrated Sound | Realtek ALC1220 |
| Internal USB 3.0 Header | Yes |
| Length | 170 mm |
| M.2 Support | Yes |
| Maximum Installed Processors | 0 (1) |
| Maximum memory capacity | 32GB |
| Memory Bus Speed | 3466+(OC) / 3200(OC) / 2933 / 2667 / 2400 / 2133 MHz |
| Memory channel | Dual |
| Memory slot | 2 x DIMM |
| Memory speed | DDR4 - 2133 DDR4 - 2400 DDR4 - 2666 DDR4 - 2933 DDR4 - 2933(OC) DDR4 - 3200(OC) DDR4 - 3466+(OC) |
| Memory Type ECC | ECC/Non-ECC |
| Memory Type R/U | UDIMM (Unbuffered) |
| Motherboard form factor | ITX |
| Motherboard Power Connectors | 4 + 4-Pin |
| Multi GPU Support | No |
| Network Interface Type | 802.11ac WiFi LAN Wired Gigabit LAN (10/100/1000) |
| Network Speeds Supported | 10/100/1000 Mbps |
| Number of PCI Express Slots | 1 x PCI Express 3.0 x16 |
| On-board Audio Type | 7.1 |
| On-board RGB Control | ASRock RGB LED |
| Operating Systems Supported | Microsoft Windows 10 64-bit |
| Other Connectors | 1 x M.2, M Key (Type 2280)1 x AMD Fan LED header |
| Power connector port | 1 x 20+4-pin ATX1 x 4+4-pin ATX12V |
| Primary GPU Interface | PCIe 3.0 (x16) |
| QPI Speed | N/A |
| RAID Format | RAID 0, 1, 10 |
| RAID Support via | SATA |
| Raid supported | Yes |
| Refresh rate | 60Hz 2Ms Response Time |
| RGB Header Type | 3-Pin ARGB |
| RJ-45 ports | 1 x RJ-45 |
| SATA III Support | Yes |
| SATA Supported | Yes |
| Skip audio test | No |
| Software Included | Utilities, AntiVirus Software (Trial Version), Google Chrome Browser and Toolbar |
| Supported processors | Ryzen 2nd GenerationRyzen 1st GenerationRyzen with Vega graphics |
| Thunderbolt | No |
| USB 3.0 Support | Yes |
| USB 3.1 Support | Yes |
| USB Connectors | 1 x USB 3.01 x USB 2.0 |
| USB Ports | 6 port(s) |
| VGA connection | No |
| Water Cooled | No |
| WiFi Speed | 433 Mbps |
| Wireless LAN | Yes |
| Wireless Network | Yes |
