ASRock X470 PowerSeries
Share: ![]()
![]()
![]()
![]()
![]()
![]()
eBay
| Brand | ASRock |
| EAN | 4717677335200 |
| Model | 90-MXB7J0-A0UAYZ |
| MPN | 90-MXB7J0-A0UAYZ |
| ASIN | B07C1Z4RMT |
| 64-bit Support | Yes |
| Addressable RGB | No |
| AMD CrossFire Support | 2-Way CrossFire |
| Audio | Realtek ALC1220 7.1 HD Audio |
| Audio line in ports | 1 x 3.5mm Jack |
| Audio Line Out Ports | 3 x 3.5mm Jacks |
| Bluetooth | Yes |
| Bluetooth version | 4.2 |
| Board dimensions | 305 x 244 mm |
| Chipset | AMD X470 |
| Chipset manufacturer | AMD |
| Cooling fan support | 1 x CPU fan1 x CPU/Water Pump fan3 x Chassis/Water Pump fans |
| CPU Socket | AM4 |
| Displayport connection | No |
| Drivers | Included |
| DVI connection | No |
| Firewire | No |
| Form factor | ATX |
| Front panel connectors | 1 x Front Panel1 x Front Audio |
| HDMI connection | Yes |
| HDMI Port | 1 x HDMI |
| Integrated Graphics Supported | Yes |
| Internal USB 3.0 Header | Yes |
| Length | 244 mm |
| M.2 Support | Yes |
| Maximum Installed Processors | 0 (1) |
| Maximum memory capacity | 64GB (4x16GB) |
| Maximum RAM | 64 GB |
| Memory Bus Speed | Up to 3466+ MHz |
| Memory speed | DDR4 - 2133 DDR4 - 2400 DDR4 - 2666 DDR4 - 2933 DDR4 - 3200(OC) DDR4 - 3466+(OC) |
| Memory Type ECC | ECC/Non-ECC |
| Memory Type R/U | UDIMM (Unbuffered) |
| Motherboard Power Connectors | 4 + 8-Pin |
| Multi GPU Support | Both |
| Network Interface Type | 802.11ac WiFi LAN Wired Gigabit LAN (10/100/1000) |
| Network Speeds Supported | 10/100/1000 Mbps |
| Number of PCI Express Slots | 2 x PCI Express 3.0 x16 (@ x16, dual x8/x8)1 x PCI Express 2.0 x16 (@ x4)2 x PCI Express 2.0 x1 |
| Number of SATA Ports | 8 port(s) |
| On-board Audio Type | 7.1 |
| On-Board Graphics Connectors | HDMI 1.4 |
| On-board RGB Control | None |
| Power connector port | 1 x 20+4-pin ATX1 x 4+4-pin ATX12V1 x 4-pin ATX12V |
| Primary GPU Interface | PCIe 3.0 (x16) |
| QPI Speed | N/A |
| RAID Support via | SATA |
| Raid supported | RAID 0, 1, 10 |
| RJ-45 ports | 1 x RJ-45 |
| SATA III Support | Yes |
| SATA Support | SATA3 / M.2 |
| SATA Supported | Yes |
| Skip audio test | Yes |
| Storage Mode Support | AHCI Hot Plug NCQ RAID 0 (SATA 0~5 ONLY) RAID 1 (SATA 0~5 ONLY) RAID 10 (SATA 0~5 ONLY) |
| Thunderbolt | No |
| USB 3.0 Support | Yes |
| USB 3.1 Support | Yes |
| USB Connectors | 2 x USB 3.02 x USB 2.0 |
| VGA connection | No |
| Water Cooled | No |
| Width | 305 mm |
| WiFi Speed | 433 Mbps |
| Wireless LAN | 802.11ac |
| Wireless Network | Yes |
