| Brand | ASUS |
| EAN | 4712900986273 |
| ASIN | B07DHVRM3K |
| Model | CHROMEBOX3-N006U |
| MPN | CHROMEBOX3-N006U |
| SKU | CHROMEBOX3-N006U |
| Architecture | Coffee Lake |
| Base GPU Speed | 300 MHz |
| Bluetooth | Yes |
| Bluetooth version | 4 |
| Burst frequency | 4.0 GHz |
| Bus Type | OPI |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| Card reader integrated | Yes |
| Chassis type | Mini PC |
| Chipset | Integrated |
| Clock speed | 1.8 GHz |
| Colour | Black |
| Compatible memory cards | MicroSD (TransFlash) |
| Configurable TDP-down frequency | 800 MHz |
| CPU Cache | 8MB |
| CPU Included | Yes |
| CPU Model | 8550U |
| CPU Socket | N/A |
| CPU Type | Intel Core i7 |
| DC-in jack | Yes |
| Depth | 148.5 mm |
| Dimensions | 148.5 x 40 x 148.5 (mm WxHxD) |
| Discrete GPU | No |
| Discrete graphics adapter | No |
| Discrete graphics adapter model | Not available |
| Display included | No |
| DVI port | No |
| ECC supported by processor | No |
| Edition | ChromeBox3-N006U |
| Embedded options available | No |
| Enhanced intel speedstep technology | Yes |
| Ethernet LAN | Yes |
| Ethernet LAN ports | 1 |
| Execute disable bit | Yes |
| Front panel | 1 x 3-in-1 Card Reader 1 x Headphone/Mic Combo 2 x USB 3.1 Gen1 Type-A |
| GPU Memory Size | Shared |
| Graphics interface | On-board |
| Idle states | Yes |
| Intel 64 | Yes |
| Intel clear video technology | Yes |
| Intel enhanced halt state | Yes |
| Intel flex memory access | Yes |
| Intel trusted execution technology | No |
| Intel TSX-NI | Yes |
| Internal memory | 16384 MB |
| Keyboard / mouse included | No |
| Manufacturing process | 14 nm |
| Maximum displays supported | 3 |
| Maximum GPU Resolution | 4096x2304 (4K) @60Hz |
| Maximum GPU Speed | 1150 MHz |
| Maximum internal memory supported by processor | 32768 MB |
| Maximum memory capacity | 16GB |
| Maximum number of PCI Express lanes | 12 |
| Maximum TDP | 15 W |
| Memory bandwidth supported by processor | 34.1 GB/s |
| Memory channels | Dual (2) |
| Memory clock speeds supported by processor | 2133,2400 MHz |
| Memory included | Yes |
| Memory speed | DDR4 - 2400 |
| Memory Type ECC | Non-ECC |
| Memory Type R/U | UDIMM (Unbuffered) |
| Motherboard form factor | Bespoke/Custom |
| Multi-GPU Configuration | No |
| Network Chip | 1 x 802.11ac WiFi + BT4.2 1 x Gigabit LAN |
| Network Interface Type | 802.11ac WiFi LAN Wired Gigabit LAN (10/100/1000) |
| On-board graphics adapter | Yes |
| On-board graphics adapter DirectX version | 12.0 |
| On-board graphics adapter family | Intel® UHD Graphics |
| On-board graphics adapter ID | 0x5917 |
| On-board graphics adapter model | Intel® UHD Graphics 620 |
| On-board/Integrated Graphics | Yes |
| On/off button | Yes |
| Operating system | Chrome OS |
| Operating system included | Yes |
| Optical drive type | No |
| PCI Express configurations | 2 x 1,1 x |
| PCI Express slots version | 3.0 |
| Processor ARK ID | 122589 |
| Processor boost frequency | 4.00 GHz |
| Processor cache type | Smart Cache |
| Processor codename | Kaby Lake R |
| Processor family | 8th gen Intel® Core™ i7 |
| Processor frequency | 1.80 GHz |
| Processor manufacturer | Intel |
| Processor model | i7-8550U |
| Processor operating modes | 64-bit |
| Processor package size | 42 x 24 mm |
| Processor socket | BGA 1356 |
| PSU Wattage | 90 W |
| Remote control included | No |
| SSD Capacity | 256 GB |
| Stepping | Y0 |
| Storage drive included | Yes |
| Storage drive type | SSD |
| Supported instruction sets | AVX 2.0,SSE4.1,SSE4.2 |
| Thermal monitoring technologies | Yes |
| Tjunction | 100 °C |
| Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
| Total storage capacity | 262144 MB |
| Unlocked CPU | No |
| VESA Mountable | Yes |
| Wi-Fi | Yes |
| Wi-Fi standards | 802.11a,Wi-Fi 5 (802.11ac),802.11b,802.11g,Wi-Fi 4 (802.11n) |
| Wired network | Yes |
