ASUS M5A97 EVO R2.0 SB950 Socket AM3+ Motherboard
101.99 GBP
Powerful AM3+ support with the Asus M5A97 EVO R2.0 ATX motherboard, dual‑channel DDR3 up to 32 GB, six SATA III and two eSATA ports, Realtek ALC892 7.1‑channel audio, Gigabit LAN, and CrossFireX capability.
Share: ![]()
![]()
![]()
![]()
![]()
![]()
eBay
Comp Advance
| Brand | ASUS |
| EAN | 4719543188538 |
| Model | 90-MIBJJ0-G0EAY0MZ |
| MPN | 90-MIBJJ0-G0EAY0MZ |
| ASIN | B008RPZ5H8 |
| ACPI version | 2.0a |
| Audio chip | Realtek ALC892 |
| Audio output | 6 |
| Audio output channels | 7.1 channels |
| BIOS memory size | 64 Mbit |
| BIOS type | UEFI |
| Bundled software | ASUS Utilities ASUS Update |
| Cables included | SATA |
| Chassis intrusion connector | Yes |
| Clear CMOS jumper | Yes |
| Compatible processor series | AMD Phenom FX,AMD Phenom II X2,AMD Phenom II X3,AMD Phenom II X4,AMD Phenom II X6,AMD Phenom II X8 |
| Component for | PC |
| Controller interface type | AMD SB950 |
| Cooling type | Passive |
| CPU fan connector | Yes |
| Depth | 244 mm |
| Drivers included | Yes |
| eSATA ports quantity | 2 |
| Ethernet interface type | Gigabit Ethernet |
| Ethernet LAN | Yes |
| Front panel audio connector | Yes |
| LAN controller | Realtek RTL8111F |
| Maximum internal memory | 32 GB |
| Maximum number of SMP processors | 1 |
| Memory channels | Dual-channel |
| Memory slots type | DIMM |
| Microphone in | Yes |
| Motherboard chipset | AMD 970 |
| Motherboard chipset family | AMD |
| Motherboard form factor | ATX |
| Non-ECC | Yes |
| Number of chassis fan connectors | 3 |
| Number of memory slots | 4 |
| On-board graphics adapter | No |
| Parallel processing technology support | Quad-GPU CrossFireX |
| PCI Express configurations | 1x4,1x16,2x1 |
| Quick installation guide | Yes |
| RAID levels | 0,1,5,10 |
| S/PDIF out connector | Yes |
| S/PDIF out port | Yes |
| Supported memory clock speeds | 1066,1333,1866,2133 MHz |
| Supported storage drive interfaces | Serial ATA III |
| System bus rate | 4.8 GT/s |
| TPM connector | Yes |
| Trial software | AntiVirus |
| Unbuffered memory | Yes |
| USB 2.0 ports quantity | 8 |
| Width | 305 mm |
