IBM Lenovo ThinkSystem SR635
Compact 1U rack server powered by an Intel Xeon E5‑2697V4, 18 cores and 36 threads, with 16 GB DDR4 memory, 900 W power supply, hot‑swap drives, dual QPI links, ECC, and Broadcom Gigabit Ethernet.
Share: ![]()
![]()
![]()
![]()
![]()
![]()
eBay
| Brand | Lenovo |
| EAN | 0889488412457 |
| Model | 8869N2G |
| MPN | 8869N2G |
| ASIN | B01I5CB7Q0 |
| Bus Type | QPI |
| Cabling technology | 10/100/1000Base-T(X) |
| Chassis type | Rack (1U) |
| Compatible operating systems | Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware vSpher |
| Depth | 734 mm |
| ECC | Yes |
| ECC supported by processor | Yes |
| Embedded options available | No |
| Enhanced intel speedstep technology | Yes |
| Ethernet interface type | Fast Ethernet,Gigabit Ethernet |
| Ethernet LAN | Yes |
| Execute disable bit | Yes |
| Height | 43 mm |
| Hot-swap | Yes |
| Idle states | Yes |
| Intel 64 | Yes |
| Intel Demand Based Switching | Yes |
| Intel enhanced halt state | Yes |
| Intel flex memory access | No |
| Intel trusted execution technology | Yes |
| Intel TSX-NI | Yes |
| Internal memory | 16 GB |
| Internal memory type | DDR4-SDRAM |
| LAN controller | Broadcom BCM5719 |
| Maximum internal memory supported by processor | 1536 GB |
| Maximum number of PCI Express lanes | 40 |
| Memory channels supported by processor | Quad |
| Memory clock speed | 2133 MHz |
| Memory clock speeds supported by processor | 1600,1866,2133,2400 MHz |
| Memory slots | 24 |
| Number of QPI links | 2 |
| On-board graphics adapter | Yes |
| Operating system installed | No |
| Optical drive type | No |
| PCI Express slots version | 3.0 |
| Power supply | 900 W |
| Processor ARK ID | 91755 |
| Processor boost frequency | 3.6 GHz |
| Processor cache | 45 MB |
| Processor cache type | Smart Cache |
| Processor codename | Broadwell |
| Processor cores | 18 |
| Processor family | Intel® Xeon® E5 v4 |
| Processor frequency | 2.3 GHz |
| Processor lithography | 14 nm |
| Processor model | E5-2697V4 |
| Processor operating modes | 64-bit |
| Processor package size | 52.5 x 51 mm |
| Processor series | Intel Xeon E5-2600 v4 |
| Processor socket | LGA 2011-v3 |
| RAID support | Yes |
| Redundant fans support | Yes |
| S.M.A.R.T. support | Yes |
| Stepping | B0 |
| Supported instruction sets | AVX 2.0 |
| System bus rate | 9.6 GT/s |
| Tcase | 79 °C |
| Thermal monitoring technologies | Yes |
| Width | 434 mm |
