Intellinet Managed Ethernet Media Converter
A sleek black metal converter turns one SC fiber link into Gigabit Ethernet, handling up to 550 m at 850 nm. It runs on 5 V DC, shows LAN/Link/Power LEDs, and meets FCC/CE standards for reliable wired connectivity.
Share: ![]()
![]()
![]()
![]()
![]()
![]()
eBay
| Brand | Manhattan |
| EAN | 0031112866413 |
| Model | 506533 |
| MPN | 506533 |
| SKU | 506533 |
| ASIN | B004I6OE18 |
| Certification | FCC, CE |
| Connectivity technology | Wired |
| DC-in jack | Yes |
| Depth | 107 mm |
| Ethernet interface type | Gigabit Ethernet |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| External power adapter | Yes |
| Fiber mode structure | Multi-mode |
| Fiber optic connector | SC |
| Fiber ports quantity | 1 |
| Height | 26 mm |
| Housing material | Metal |
| Input voltage | 5 V |
| Internal | No |
| LED indicators | LAN,Link,Power |
| Manual | Yes |
| Maximum data transfer rate | 1000 Mbit/s |
| Maximum transfer distance | 550 m |
| Networking standards | IEEE 802.3ab,IEEE 802.3z |
| Sensitivity | -20 dBmW |
| Wavelength | 850 nm |
| Weight | 500 g |
| Width | 70 mm |
