MSI B250 PRO-VDH Motherboard
250.00 GBP
MSI B250M Pro‑VDH micro‑ATX equips Intel LGA1151 CPUs with dual‑channel DDR4 up to 64 GB, one M.2 slot, six SATA III ports, Gigabit Ethernet, HDMI, DVI‑D and VGA outputs, 7.1‑ch audio, USB 3.1 Gen 1 Type‑A/C, and a single PCIe x16 slot for graphics or expansion.
Share: ![]()
![]()
![]()
![]()
![]()
![]()
eBay
taqagroup.iq
| Brand | MSI |
| EAN | 4719072489892 |
| Model | 7A70-003R |
| ASIN | B01MS3HKTY |
| MPN | B250M PRO-VDH |
| ATX Power connector 24-pin | Yes |
| Audio output channels | 7.1 channels |
| BIOS type | UEFI |
| Chassis intrusion connector | Yes |
| Clear CMOS jumper | Yes |
| Compatible processor series | Intel® Celeron®, Intel® Pentium® |
| Component for | PC |
| CPU fan connector | Yes |
| Depth | 9.61" (244 mm) |
| DVI-D ports | 1 |
| EPS power connector 8-pin | Yes |
| Ethernet interface type | Gigabit Ethernet |
| Ethernet LAN | Yes |
| Front panel audio connector | Yes |
| Front panel connector | Yes |
| Intel Extreme Memory Profile XMP | Yes |
| Intel Optane Memory Ready | Yes |
| LAN controller | Realtek RTL8111H |
| Linux operating systems supported | Yes |
| Maximum internal memory | 65536 MB |
| Memory channels | Dual |
| Memory slots type | DIMM |
| Memory voltage | 1.35 V |
| Microphone in | Yes |
| Motherboard chipset | Intel® B250 |
| Motherboard chipset family | Intel |
| Motherboard form factor | Micro ATX |
| Non-ECC | Yes |
| Number of chassis fan connectors | 2 |
| Number of memory slots | 4 |
| Number of SATA III connectors | 6 |
| Parallel port via internal header | Yes |
| Power source type | ATX |
| Processor socket | LGA 1151 (Socket H4) |
| Serial port via internal header | Yes |
| Supported memory clock speeds | 2133,2400 MHz |
| Supported memory module capacities | 16GB |
| Supported storage drive types | HDD,SSD |
| TPM connector | Yes |
| USB 3.0 (3.1 Gen 1) Type-A ports quantity | 3 |
| Wi-Fi | No |
| Width | 8.98" (228 mm) |
| Windows operating systems supported | Yes |
