Experience smooth multitasking on this 15.6” Full HD notebook powered by an Intel i7‑6500U and NVIDIA GeForce 940M, paired with 8 GB DDR4 RAM (up to 12 GB) and a combined 1 TB HDD plus 16 GB SSD for fast storage. The SonicMaster sound system delivers clear audio, while Wi‑Fi 5 and Bluetooth 4.0 keep you connected. The slim 2 kg chassis houses a full‑size keyboard, numeric keypad, and an integrated webcam, all running Windows 10 Home.
| Brand | ASUS |
| EAN | 4712900172799 |
| ASIN | B01A6XLR2U |
| Model | K501UB-DM021T |
| MPN | K501UB-DM021T |
| AC adapter frequency | 50 - 60 Hz |
| AC adapter input voltage | 100 - 240 V |
| AC adapter output current | 3.42 A |
| AC adapter output voltage | 19 V |
| AC adapter power | 65 W |
| Aspect ratio | 16:9 |
| Audio system | SonicMaster |
| Bluetooth | Yes |
| Bluetooth version | 4.0 |
| Built-in microphone | Yes |
| Bus Type | OPI |
| Cable lock slot | No |
| Card reader integrated | Yes |
| CardBus PCMCIA slot type | No |
| Charging port type | DC-in jack |
| Compatible memory cards | SD,SDHC |
| Configurable TDP-down | 7.5 W |
| Configurable TDP-down frequency | 800 MHz |
| Depth | 255 mm |
| Discrete graphics adapter | Yes |
| Discrete graphics adapter memory | 2 GB |
| Discrete graphics adapter model | NVIDIA® GeForce® 940M |
| Discrete graphics memory type | GDDR3 |
| Display Diagonal | 39.6 cm (15.6") |
| Display resolution | 1920 x 1080 pixels |
| Docking connector | No |
| DVI port | No |
| ECC supported by processor | No |
| Embedded options available | No |
| Enhanced intel speedstep technology | Yes |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10,1000,100 Mbit/s |
| Execute disable bit | Yes |
| ExpressCard slot | No |
| Form Factor | Clamshell |
| Front camera | Yes |
| FSB Parity | No |
| Full-size keyboard | Yes |
| Graphics & IMC lithography | 14 nm |
| Graphics adapter Open GL support | Yes |
| HD type | Full HD |
| HDD Capacity | 1000 GB |
| HDD interface | SATA III |
| HDD size | 2.5" |
| HDMI ports quantity | 1 |
| Height | 21.7 mm |
| Idle states | Yes |
| Intel 64 | Yes |
| Intel clear video technology | Yes |
| Intel Demand Based Switching | No |
| Intel Dual Display Capable Technology | No |
| Intel enhanced halt state | Yes |
| Intel Fast Memory Access | No |
| Intel FDI Technology | No |
| Intel flex memory access | Yes |
| Intel HD Graphics | Yes |
| Intel rapid storage technology | No |
| Intel Secure Key Technology version | 1.00 |
| Intel trusted execution technology | No |
| Intel TSX-NI | Yes |
| Internal memory | 8 GB |
| LED backlight | Yes |
| Lightscribe | No |
| Maximum internal memory | 12 GB |
| Maximum on-board graphics adapter memory | 1.74 GB |
| Microphone in | No |
| Numeric keypad | Yes |
| On-board graphics adapter | Yes |
| On-board graphics adapter base frequency | 300 MHz |
| On-board graphics adapter family | Intel® HD Graphics |
| On-board graphics adapter ID | 1916 |
| On-board graphics adapter model | Intel® HD Graphics 520 |
| On-board graphics adapter OpenGL version | 4.4 |
| Operating system architecture | 64-bit |
| Operating system installed | Windows 10 Home |
| Optical drive type | No |
| Password Protection | Yes |
| Password protection type | BIOS,HDD,User |
| PCI Express configurations | 1x4,4x1 |
| PCI Express slots version | 3.0 |
| Pointing device | Touchpad |
| Processor ARK ID | 88194 |
| Processor boost frequency | 3.1 GHz |
| Processor cache | 4 MB |
| Processor cache type | Smart Cache |
| Processor codename | Skylake |
| Processor family | 6th gen Intel® Core™ i7 |
| Processor manufacturer | Intel |
| Processor model | i7-6500U |
| Processor package size | 42 mm |
| Processor socket | LGA 1356 (Socket B2) |
| Product Type | Notebook |
| S/PDIF out port | No |
| SmartCard slot | No |
| SSD Capacity | 16 GB |
| Storage media | HDD+SSD |
| Supported instruction sets | SSE4.1,SSE4.2,AVX 2.0 |
| Thermal monitoring technologies | Yes |
| Touchscreen | No |
| Wi-Fi | Yes |
| Wi-Fi standards | Wi-Fi 5 (802.11ac) |
| Width | 382 mm |
| Windows keys | Yes |
