| Brand |
MSI |
| EAN |
5054629638842 |
| Model |
Z97 PC Mate |
| MPN |
Z97 PC Mate |
| ASIN |
B00K8KLW3G |
| ACPI version |
5.0 |
| Audio chip |
Realtek ALC887 |
| Audio output channels |
7.1 channels |
| BIOS memory size |
64 Mbit |
| BIOS type |
AMI |
| Chassis intrusion connector |
Yes |
| Clear CMOS jumper |
Yes |
| Compatible processor series |
Intel® Celeron®, Intel® Pentium® |
| Component for |
PC |
| CPU fan connector |
Yes |
| Depth |
220 mm |
| DVI-D ports quantity |
1 |
| Ethernet interface type |
Fast Ethernet |
| Ethernet LAN |
Yes |
| Front panel audio connector |
Yes |
| Internal memory |
32 GB |
| LAN controller |
Realtek 8111G |
| Memory channels |
Dual-channel |
| Memory slots type |
DIMM |
| Motherboard chipset |
Intel® Z97 |
| Motherboard chipset family |
Intel |
| Motherboard form factor |
ATX |
| Non-ECC |
Yes |
| Number of SATA connectors |
6 |
| PCI Express x16 slots |
2 |
| Processor socket |
LGA 1150 (Socket H3) |
| Supported memory clock speeds |
1066,1333,1600,1866,2000,2133,2200,2400,2600,2666,2800,3000 MHz |
| Supported memory types |
DDR3-SDRAM |
| Supported storage drive interfaces |
Serial ATA,Serial ATA III |
| TPM connector |
Yes |
| USB 2.0 ports quantity |
4 |
| Width |
305 mm |
