Ultra‑short throw NEC UM301W projects vivid WXGA 1280x800 images with 3000 ANSI lumens, 3LCD tech and dual HDMI, VGA, USB ports; built‑in speaker, manual focus, 1.4× digital zoom, Kensington lock, auto‑off.
| Brand | NEC |
| Model | 60003840 |
| MPN | 60003840 |
| SKU | 2348453 |
| EAN | 5028695611405 |
| ASIN | B00S2B17DI |
| AC input frequency | 50 - 60 Hz |
| AC input voltage | 100 - 240 V |
| AC power in | Yes |
| Analog signal format system | NTSC,NTSC 3.58,NTSC 4.43,PAL,PAL 60,PAL M,PAL N,SECAM |
| Aperture range | 1.8 - 1.8 |
| Audio (L,R) in | 1 |
| Auto power off | Yes |
| Black ink page yield | 350 pages |
| Black ink volume | 6.2 ml |
| Brand compatibility | Epson |
| Built-in speakers | Yes |
| Bulb power | 170 W |
| Cable Lock Slot | Yes |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| Cables included | AC,VGA |
| Card reader integrated | No |
| Cartridge capacity | Standard Yield |
| Certification | CE, Gost-R, TÜV GS |
| Colour | White |
| Contrast ratio | 6000:1 |
| DC-in jack | Yes |
| Depth | 428 mm |
| Digital zoom | 1.4x |
| DVI port | No |
| Ethernet LAN | Yes |
| Fixed focal length | 4.78 mm |
| Focus | Manual |
| Full HD | No |
| Handheld remote control | Yes |
| HDMI | 2 |
| HDMI connector type | Full-size |
| Height | 112 mm |
| Horizontal scan range | 15 - 100 kHz |
| Ink type | Pigment-based ink |
| LED indicators | Yes |
| Light source type | Lamp |
| Manual | Yes |
| Matrix size | 1.5 cm (0.59") |
| Matrix type | 3-panel (p-Si TFT active) |
| Maximum digital resolution | 1920 x 1200 pixels |
| Maximum power consumption | 285 W |
| Microphone in | Yes |
| Mobile High-Definition Link | Yes |
| Mounting brackets included | Yes |
| Multipack | No |
| Native aspect ratio | 16:10 |
| Noise Level | 27 dB |
| OEM code | C13T27014012 |
| Offset | 81% |
| On screen display | Yes |
| Operating relative humidity | 20 - 80 % |
| Package type | Blister |
| Password protection | Yes |
| Password Protection | Yes |
| PC Audio in | Yes |
| Power consumption | 227 W |
| Power consumption (StandBy) | 0.4 W |
| Power consumption economy mode | 190 W |
| Power source | AC |
| Print technology | Inkjet printing |
| Printing colours | Black |
| Product Type | Desktop projector |
| Projection distance | 0.11 - 0.51 m |
| Projector brightness | 3000 ANSI lumens |
| Projector native resolution | 1280x800 |
| Quick start guide | Yes |
| Remote control type | IR |
| RMS rated power | 20 W |
| RoHS compliance | Yes |
| Screen size compatibility | 1473.2 - 2794 mm (58 - 110") |
| Serial interface type | RS-232 |
| Service life of lamp | 5000 h |
| Service life of lamp economic mode | 8000 h |
| Supported aspect ratios | 16:10,16:9 |
| Supported Graphics Resolutions | 720x480 |
| Supported video modes | 1080i,1080p,480i,480p,576i,576p,720p |
| Throw ratio | 0.36:1 |
| TVI port | No |
| Type | Original |
| USB connector type | USB Type-A,USB Type-B |
| Vertical scan range | 50 - 120 Hz |
| Weight | 5.5 kg |
| Width | 378 mm |
