Shuttle XH110 Barebones mini PC - Components > Barebone PC
Slim, low‑profile barebone with Intel H110 chipset, dual‑channel DDR3L up to 32 GB, M.2 and SATA III slots, HDMI 1.4 + DisplayPort, 5.1 HD audio, two Ethernet ports, active cooling, powered by a 90 W external adapter.
Share: ![]()
![]()
![]()
![]()
![]()
![]()
eBay
| Brand | SHUTTLE |
| EAN | 0887993000664 |
| ASIN | B01CTW5AE2 |
| Model | XH110 |
| MPN | XH110 |
| AC adapter included | Yes |
| AC adapter output current | 4.74 A |
| AC adapter output voltage | 19 |
| AC input frequency | 50 - 60 Hz |
| AC input voltage | 100 - 240 V |
| Audio output channels | 5.1 channels |
| Audio system | HD |
| BIOS memory size | 64 Mbit |
| BIOS type | AMI |
| Built-in processor | No |
| Cable lock slot | Yes |
| Cable Lock Slot | Yes |
| Cable lock slot type | Kensington |
| Certification | FCC, CE, BSMI, C-Tick, RoHS |
| Chassis type | Low Profile (Slimline) |
| Colour | Black |
| Compatible processor series | Intel® Celeron®, Intel® Pentium® |
| Cooling type | Active |
| Depth | 238 mm |
| Displayports quantity | 1 |
| Drivers included | Yes |
| ECC | No |
| Energy Star certified | Yes |
| Ethernet LAN | Yes |
| Ethernet LAN ports | 2 |
| Graphics adapter | HD Graphics |
| Graphics adapter family | Intel |
| HDMI version | 1.4 |
| Height | 72 mm |
| Intel® High Definition Audio | Yes |
| LAN controller | Intel® I211-AT, Intel I219LM |
| LED indicators | HDD, Power |
| Linux operating systems supported | Yes |
| Maximum graphics adapter memory | 1760 MB |
| Maximum internal memory | 32768 MB |
| Maximum resolution | 3840 x 2160 pixels |
| Memory channels | Dual-channel |
| Memory slots type | SO-DIMM |
| Memory voltage | 1.35 V |
| Microphone in | Yes |
| Motherboard chipset | Intel® H110 |
| Motherboard form factor | mini ITX |
| On-board graphics adapter | Yes |
| Operating relative humidity | 10 - 90 % |
| Operating system installed | No |
| Power cord included | Yes |
| Power supply | 90 W |
| Power supply type | External AC adapter |
| Processor socket | LGA 1151 (Socket H4) |
| Product Type | PC barebone |
| Safety | CB, BSMI, ETL |
| Storage drive sizes supported | 2.5" |
| Supported memory clock speeds | 1333,1600 MHz |
| Supported memory types | DDR3L-SDRAM |
| Supported storage drive types | HDD,SSD |
| Thermal design power | 65 W |
| USB 2.0 ports quantity | 4 |
| VESA mounting | Yes |
| VESA Mounting | Yes |
| Weight | 2.2 kg |
| Wi-Fi | No |
| Width | 200 mm |
