| Brand |
Supermicro |
| EAN |
0672042162314 |
| ASIN |
B00L0QYX0G |
| Model |
SYS-5018R-M |
| MPN |
SYS-5018R-M |
| BIOS type |
AMI |
| Bluetooth |
No |
| Built-in camera |
No |
| Card reader integrated |
No |
| Certification |
RoHS |
| Chassis type |
Rack (1U), - |
| Compatible processor series |
Intel® Xeon® |
| Depth |
503 mm |
| ECC |
Yes |
| Ethernet LAN |
Yes |
| Graphics adapter |
AST2400 |
| Graphics adapter family |
Aspeed |
| Height |
43 mm |
| LAN controller |
Intel® I350-AM2, Realtek RTL8201N |
| LED indicators |
Yes |
| Maximum internal memory |
512 GB |
| Motherboard chipset |
Intel® C612 |
| Networking features |
Gigabit Ethernet LAN |
| Number of memory slots |
8 |
| Number of SATA connectors |
10 |
| Number of storage drives supported |
4 |
| Optical drive type |
No |
| Package depth |
750 mm |
| Package Height |
216 mm |
| Package width |
610 mm |
| Power LED |
Yes |
| Power requirements |
100 - 240V, 50-60Hz |
| Power supply |
350 W |
| Processor socket |
LGA 2011 (Socket R) |
| RAID levels |
0,1,10 |
| Redundant fans support |
Yes |
| Storage drive interface |
Serial ATA III |
| Storage drive sizes supported |
3.5" |
| Supported memory clock speeds |
1600,1866,2133 MHz |
| Wi-Fi |
No |
| Width |
437 mm |
