Synology DS1618+ 6-Bay RAID NAS
1091.40 GBP
Powerful yet compact, the DS1618+ houses a quad‑core Intel Atom C3538 at 2.1 GHz with 4 GB DDR4 RAM, supporting up to six hot‑swap SATA drives for RAID 0/1/5/6/10/JBOD, four Gigabit Ethernet ports, dual USB 3.0, eSATA and a PCIe slot for expansion.
Share: ![]()
![]()
![]()
![]()
![]()
![]()
eBay
Hunt Office
| Brand | Synology |
| EAN | 4711174722976 |
| ASIN | B07D3JD8B6 |
| Model | Z661388 |
| MPN | Z661388 |
| SKU | Z661388 |
| Bays | 6 Bay |
| Built-in devices | Led panel |
| Cables included | 2 x network cable |
| Compliant Standards | DLNA CERTIFIED |
| Compression format | MJPEG, H.264, H.265 |
| Cooling | Fan |
| CPU Cores | Quad Core |
| CPU Model | C3538 |
| CPU Speed | 2.1 GHz |
| CPU Type | Intel Atom |
| Data Link Protocol | 10Mb LAN, 100Mb LAN, GigE |
| Device type | NAS server |
| Dimensions | 282 x 166 x 243 (WxHxD mm) |
| Disk form factor | 2.5 & 3.5 |
| DOM Module | No |
| Drive Form Factor Support | 6 x 2.5"/3.5" |
| Drive Interface Support | 6 x SATA III - 6Gb/s |
| Enclosure Type | Adapter |
| Encryption algorithm | SSL, TLS, AES-NI |
| Expansion bays | 6 (total) / 6 (free) x hot-swap - 2.5" / 3.5" |
| Expansion slots | 1 x PCIe 3.0 x8 |
| External Connectivity | 2 x eSATA 4 x RJ45 3 x USB 3.0 |
| Host connectivity | Gigabit Ethernet |
| Humidity range operating | 5 - 95% |
| Image Resolution | 1280x720, 1920x1080, 2048x1536, 2591x1944, 3840x2160 |
| Internal Flash Memory | No |
| LAN Type | 10/100/1000 |
| Max supported capacity | 72 TB |
| Maximum power consumption | 56.86 W |
| Maximum RAM Memory Supported | 32GB |
| NAS Form Factor | Desktop |
| Noise Level | 23.7 dB(A) |
| OS Required | Apple MacOS X 10.11 or later, Microsoft Windows 7 / 10 |
| Pc connection type | Ethernet 1Gbps |
| Power Consumption Stand by | 25.76 Watt |
| Power Device | Internal power supply |
| Power Provided | 250 Watt |
| Processors installed | 1 x Intel Atom C3538 2.1 GHz |
| RAID Level | RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, JBOD |
| RAM Memory | 4 GB (installed) / 32 GB (supported) - DDR4 |
| RAM Memory Included | 4GB (4x1GB) |
| RAM Memory Type | DDR4 |
| Remote Management Protocol | SNMP, Telnet, HTTP, HTTPS, TFTP, SSH |
| Software Included | McAfee AntiVirus (Trial) |
| Specification | No |
| Total Storage Included | N/A |
| Type | RAID |
| USB 2.0 / USB3.0 | No |
| USB Support | USB3.0 |
| Voltage required | AC 120/230 V (50/60 Hz) |
| Weight | 5.05 kg |
