Name: 8MB Cache, 4 Cores, 8 Threads Intel Xeon Processors
Brand: Intel
SKU: ID10603421
Availability: InStock

8MB Cache, 4 Cores, 8 Threads Intel Xeon Processors

402.25 USD

Intel Xeon E3‑1245 v6 offers four cores and eight threads running at 3.7 GHz, boosting to 4.1 GHz with Intel Turbo Boost, backed by an 8 MB Smart Cache and dual‑channel DDR4 memory up to 64 GB. The processor supports AVX‑2, SSE4.1/4.2, Hyper‑Threading, ECC, and integrated HD Graphics P630 capable of 4K output via HDMI or DisplayPort, making it ideal for high‑performance server and workstation workloads.

BX80677E31245V6 Intel Xeon E3-1245v6 4 Core 3.70GHz LGA 1151 8 MB L3 Processor

ETechBuy.com

402.25 USD

11-03-2026 12:58:28

Brand	Intel
EAN	0735858328128
ASIN	B06XXFGYFZ
Model	BX80677E31245V6
MPN	BX80677E31245V6
Box	Yes
Bus bandwidth	8
Bus Type	DMI3
Bus type units	GT/s
Compatibility	Server Board S1200SPLR
Component for	Server/Workstation
Cooler included	Yes
ECC	Yes
Embedded options available	No
Enhanced intel speedstep technology	Yes
Execute disable bit	Yes
Graphics output	eDP/DP/HDMI/DVI
Idle states	Yes
Intel 64	Yes
Intel clear video technology	Yes
Intel enhanced halt state	Yes
Intel Secure Key Technology version	1.00
Intel trusted execution technology	Yes
Intel TSX-NI	Yes
Launch date	Q1'17
Market segment	SRV
Maximum graphics adapter memory	64 GB
Maximum internal memory	65536 MB
Maximum number of PCI Express lanes	16
Maximum on-board graphics adapter memory	1.7 GB
Memory channels	Dual-channel
Memory clock speeds supported by processor	1866,2400 MHz
Memory types supported by processor	DDR3L-SDRAM,DDR4-SDRAM
On-board graphics adapter	Yes
On-board graphics adapter 4K support	Yes
On-board graphics adapter base frequency	350 MHz
On-board graphics adapter DirectX version	12.0
On-board graphics adapter ID	0x191D
On-board graphics adapter model	Intel® HD Graphics P630
On-board graphics adapter OpenGL version	4.4
Package depth	116 mm
Package Height	101 mm
Package width	70 mm
PCI Express CEM Revision	3.0
PCI Express configurations	1x16,1x8+2x4,2x8
Processor ARK ID	97473
Processor boost frequency	4.1 GHz
Processor brand name	Intel Xeon
Processor cache type	Smart Cache
Processor code	SR32B
Processor codename	Kaby Lake
Processor cores	4
Processor family	Intel® Xeon® E3 v6
Processor frequency	3.7 GHz
Processor lithography	14 nm
Processor manufacturer	Intel
Processor model	E3-1245 v6
Processor package size	37.5 x 37.5 mm
Processor socket	LGA 1151 (Socket H4)
Product family	Intel Xeon Processors
Product Type	Processor
Scalability	1S
Status	Launched
Stepping	B0
Supported instruction sets	AVX 2.0,SSE4.1,SSE4.2
Thermal monitoring technologies	Yes
VID voltage range	0.55 - 1.52 V

8MB Cache, 4 Cores, 8 Threads Intel Xeon Processors
