Intel i5-6600 Quad-Core CPU
Quad‑core Intel Core i5‑6600 runs at 3.3 GHz with a 3.9 GHz boost, powered by a 14 nm Skylake core and 6 MB Smart Cache. It supports dual‑channel DDR4 up to 2133 MHz, delivers HD 530 integrated graphics with 1.74 GB shared memory, and operates at 65 W TDP.
Share: ![]()
![]()
![]()
![]()
![]()
![]()
eBay
| Brand | Intel |
| EAN | 0735858301015 |
| ASIN | B0742CVYN4 |
| Model | BX80662I56600 |
| MPN | BX80662I56600 |
| Box | Yes |
| Bus bandwidth | 8 |
| Bus Type | DMI3 |
| Bus type units | GT/s |
| Cache memory | 6 MB |
| Component for | PC |
| Cooler included | Yes |
| ECC | No |
| Embedded options available | No |
| Enhanced intel speedstep technology | Yes |
| Execute disable bit | Yes |
| Graphics & IMC lithography | 14 nm |
| Graphics output | eDP/DP/HDMI/DVI |
| Idle states | Yes |
| Intel 64 | Yes |
| Intel clear video technology | Yes |
| Intel enhanced halt state | Yes |
| Intel Identity Protection Technology version | 1.00 |
| Intel trusted execution technology | Yes |
| Intel TSX-NI | Yes |
| L2 cache | 6144 KB |
| Launch date | Q3'15 |
| Market segment | DT |
| Maximum graphics adapter memory | 1740 MB |
| Maximum internal memory | 64 GB |
| Maximum number of PCI Express lanes | 16 |
| Maximum on-board graphics adapter memory | 1.74 GB |
| Memory channels | Dual-channel |
| Memory clock speeds supported by processor | 2133,1333,1600,1866 MHz |
| Memory types supported by processor | DDR3L-SDRAM,DDR4-SDRAM |
| Memory voltage supported by processor | 1.35 V |
| On-board graphics adapter | Yes |
| On-board graphics adapter 4K support | Yes |
| On-board graphics adapter base frequency | 350 MHz |
| On-board graphics adapter DirectX version | 12.0 |
| On-board graphics adapter ID | 1912 |
| On-board graphics adapter model | Intel® HD Graphics 530 |
| On-board graphics adapter OpenGL version | 4.4 |
| OpenGL support | Yes |
| Package depth | 116 mm |
| Package Height | 101 mm |
| Package width | 70 mm |
| PCI Express CEM Revision | 3.0 |
| PCI Express configurations | 1x16,2x8,1x8+2x4 |
| Processor ARK ID | 88188 |
| Processor boost frequency | 3.9 GHz |
| Processor brand name | Intel Core i5 Intel Core i5 Processor |
| Processor cache type | Smart Cache |
| Processor code | SR2BW |
| Processor codename | Skylake |
| Processor cores | 4 |
| Processor family | 6th gen Intel® Core™ i5 |
| Processor frequency | 3.3 GHz |
| Processor manufacturer | Intel |
| Processor model | i5-6600 |
| Processor package size | 37.5 x 37.5 mm |
| Processor socket | LGA 1151 (Socket H4) |
| Product name | Intel Core i5-6600 (6M Cache, up to 3.90 GHz) |
| Product Type | Processor |
| Scalability | 1S |
| Status | Discontinued |
| Stepping | R0 |
| Supported instruction sets | SSE4.2,AVX 2.0,SSE4.1 |
| Tcase | 71 °C |
| Thermal monitoring technologies | Yes |
| Thermal solution specification | PCG 2015C |
| Video compression formats | Yes |
