| Brand |
NETGEAR |
| EAN |
0606449119916 |
| MPN |
GS305P-100UKS |
| ASIN |
B072BDGQR8 |
| Model |
GS305P-100UKS |
| SKU |
GS305P-100UKS |
| 10g support |
No |
| Access Control List ACL |
Yes |
| Auto MDI/MDI-X |
Yes |
| Basic switching RJ-45 Ethernet ports quantity |
4 |
| Broadcast storm control |
Yes |
| Buffer size |
128 KB |
| Colour |
Black |
| Connectivity technology |
Wired |
| Console port |
RJ-45 |
| Depth |
101 mm |
| DHCP features |
DHCP client |
| Edition |
Unmanaged Switch |
| Electromagnetic compatibility |
CE, FCC 15 B, VCCI, C-Tick |
| Ethernet interface type |
Gigabit Ethernet |
| Ethernet LAN |
Yes |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Firmware upgradeable |
Yes |
| Flow control support |
Yes |
| Form factor |
Desktop/Wall Mount |
| Forwarding Rate |
1,448,000 pps |
| Full duplex |
Yes |
| Heat dissipation |
205.2 BTU/h |
| Height |
29 mm |
| IGMP snooping |
Yes |
| Input current |
1.25 A |
| Input voltage |
48 V |
| Jumbo frames |
9216 |
| Jumbo frames support |
Yes |
| LED indicators |
Activity,Link,Power |
| Link aggregation |
Yes |
| MAC address filtering |
Yes |
| MAC address table |
2000 entries |
| Material |
Metal |
| Maximum data transfer rate |
1 Gbit/s |
| Maximum PoE Wattage per Port |
55.5 W |
| Maximum power consumption |
60 W |
| Mean time between failures |
2,244,211 hours hours |
| Multicast support |
Yes |
| Network Protocols |
IEEE 802.1p IEEE 802.3 IEEE 802.3ab IEEE 802.3az IEEE 802.3i IEEE 802.3u IEEE 802.3x |
| Non-operating altitude |
0 - 3000 m |
| Number of cartons per pallet layer |
6 |
| On/off switch |
No |
| Package depth |
269 mm |
| Package Height |
73 mm |
| Package width |
215 mm |
| Packet buffer memory |
0.125 MB |
| PoE Support Type |
PoE |
| Port mirroring |
Yes |
| Ports Providing PoE |
4 x 10/100/1000 (Gigabit) RJ-45 (PoE Pass-through) |
| Power connector |
DC-in jack |
| Power consumption |
0.96 W |
| Power LED |
Yes |
| Power over Ethernet PoE |
Yes |
| Power supply |
External Power Supply (Included) |
| Quality of Service support |
Yes |
| Quantity per shipping (inner) case |
10 pc(s) |
| Rack mounting |
No |
| Rate limiting |
Yes |
| RJ-45 ethernet ports type |
1000 ) |
| Security algorithms |
802.1x RADIUS |
| Shipping (inner) case height |
29.8 cm |
| Shipping (inner) case length |
40 cm |
| Shipping (inner) case width |
47 cm |
| Spanning tree protocol |
Yes |
| Storage relative humidity |
5 - 95 % |
| Store and forward |
Yes |
| Switch layer |
L3 |
| Switch type |
Unmanaged |
| System event log |
Yes |
| Total Network Ports |
1 x 10/100/1000 (Gigabit) RJ-45 4 x 10/100/1000 (Gigabit) RJ-45 (PoE Pass-through) |
| Total Power over Ethernet PoE budget |
5.5 W |
| VLAN support |
Yes |
| Web-based management |
Yes |
| Weight |
410 g |
| Width |
158 mm |
