Samsung 1 TB 860 EVO M.2 SATA III SSD
Elevate your system with the Samsung 860 EVO M.2 SSD: 1 TB V‑NAND, 550 MB/s read and 520 MB/s write, 1 GB LPDDR4 cache, 256‑bit AES encryption, 600 TB endurance, and a slim 3.85 mm profile for ultra‑compact builds.
Share: ![]()
![]()
![]()
![]()
![]()
![]()
eBay
| Brand | Samsung |
| EAN | 8801643068714 |
| ASIN | B078WQT6SB |
| Model | MZ-N6E1T0BW |
| MPN | MZ-N6E1T0BW |
| 4K Random Read AS SSD | Up to 98,000 IOPS |
| 4K Random Write AS SSD | Up to 90,000 IOPS |
| Bracket | N/A |
| Capacity | 1TB |
| Colour | Black |
| Component for | PC/notebook |
| Connectivity | 1 x M.2 (SATA) |
| Controller | Samsung MJX |
| Data transfer rate | 6 Gbit/s |
| Depth | 22 mm |
| Dimensions | 22.15 x 2.38 x 80.15 mm (WxHxD) |
| Disk form factor | M.2 2280 |
| DRAM Cache Memory Type | LPDDR4 |
| Drive Size | Inches |
| Edition | 860 EVO |
| Flash Memory Type | 3-bit MLC V-NAND |
| Hardware encryption | Yes |
| Height | 2.38 mm |
| Host Controller Interface | AHCI |
| Interface | SATA 3.0 (6Gb/s) |
| Interface type | SATA III |
| Manual | Yes |
| Maximum Endurance Rating | 600TB TBW |
| Maximum Non-operating Shock | 1500G, 0.5ms, 3 axis |
| Maximum Non-operating Vibration | 20~2000Hz, 20G |
| Maximum Random Read 4K | 97,000 IOPS |
| Maximum Random Write 4K | 88,000 IOPS |
| Maximum Read | 550 MB/s |
| Maximum Write | 520 MB/s |
| Mean Time Between Failure MTBF | 1,500,000 hours |
| Memory type | SSD |
| Operating humidity | 5 ~ 95 % |
| Operating shock | 1500 G |
| Package type | Retail |
| S.M.A.R.T. support | Yes |
| Security | AES 256-bit Full Disk EncryptionTCG/Opal V2.0Encrypted Drive(IEEE1667) |
| Security algorithms | 256-bit AES |
| Shock non operating | 1,500G @ 0.5ms |
| Solid state drive | Yes |
| SSD Capacity | 1000 GB |
| SSD form factor | M.2 |
| TRIM support | Yes |
| Warranty | 5 Years |
| Weight | 8.5 g |
| Width | 80 mm |
