GIGABYTE DDR4 DIMM ATX USB3.1 Motherboard
Unleash powerful Intel Core i7 builds with the AORUS GA‑Z270X: dual‑channel DDR4 up to 64 GB, three PCIe x16 slots for SLI or CrossFire, RGB Fusion lighting, 7.1‑channel audio, M.2 and SATA III drives, USB 3.1 C, and full RAID 0/1/5/10 support.
Share: ![]()
![]()
![]()
![]()
![]()
![]()
eBay
| Brand | Gigabyte |
| EAN | 4719331846398 |
| ASIN | B01MY2EL3B |
| Model | GA-Z270X-Gaming K5 |
| MPN | GA-Z270X-Gaming K5 |
| ACPI version | 5.0 |
| Audio output channels | 7.1 channels |
| BIOS memory size | 64 Mbit |
| BIOS type | UEFI AMI |
| Clear CMOS jumper | Yes |
| Compatible processor series | Intel® Celeron®, Intel® Pentium® |
| Component for | PC |
| CPU fan connector | Yes |
| Depth | 305 mm |
| DVI-D ports quantity | 1 |
| Ethernet LAN | Yes |
| Front panel audio connector | Yes |
| Front panel connector | Yes |
| Linux operating systems supported | Yes |
| Memory channels | Dual-channel |
| Memory slots type | DIMM |
| Microphone in | Yes |
| Motherboard chipset | Intel® Z270 |
| Motherboard chipset family | Intel |
| Motherboard form factor | ATX |
| Non-ECC | Yes |
| Number of memory slots | 4 |
| Number of SATA III connectors | 6 |
| PCI Express x1 Slots | 3 |
| Processor socket | LGA 1151 (Socket H4) |
| RAID levels | 0,1,5,10 |
| S/PDIF out connector | Yes |
| Supported memory clock speeds | 2133,2400,2666,2800,3000,3200,3300,3333,3400,3466,3600,3666,3733,3800,3866 MHz |
| Supported storage drive types | HDD,SSD |
| TPM connector | Yes |
| Unbuffered memory | Yes |
| USB 2.0 connectors | 2 |
| Width | 244 mm |
